YA-800 High Speed Cross Cutting Machine

Cross Cutting Machine

1. This machine is used for cutting medical non-woven fabrics and can also be used for horizontal cutting of plastic films, cardboard trademarks, Yunnan Baiyao, plaster fabrics, etc.

2. This machine adopts microcomputer light control positioning control, status digital display, length panel setting, automatic alarm upon counting, and has power-off protection counting function.

3. Convenient length setting, high positioning accuracy, stable feeding, uniform tension, variable frequency speed regulation, easy operation and stable performance of the whole machine.

Contact: +8613705871357
  • Introduction

summary



Technical Parameters

ModelYOUAN-800
Cutting speed30-180 pieces/min
Cutting width40-800mm
Cutting length10-1200mm
accuracy±0.2mm
Host power1.5kw 380V 1400r/min
stepping motor130BYG350C
frequency converter2.2KW 220V
Power of discharge DC motor1.1KW 220V 1700r/min
Front delivery DC motor power335KW 220V 1700r/min
supply voltage~220V±10% 50Hz
External dimensions3350(L)×1150(W)×1100(H)mm
Whole machine weight1000kg
